Manual distributor 2-sections 120l/min ARAG

Reference 4712202B0

In stock: Unavailable

Part number	4712202B0
Specifications	- Modular design
Application	- For field sprayers
Properties	- Glass fiber reinforced nylon housing - Delrin® and AISI 303 stainless steel internal components - Viton® seals - Equipped with hose connections for inlet and bypass.
Consists of	- Main valve with overpressure valve - Proportional pressure control valve - 2 section valves with equal pressure collector, - Pressure gauge or pressure transducer connection
Unit	Set
Flow (l/min)	120
Version	2 valves
P max (bar)	20
Number of partial widths	2
Composed of valves	463070 + 463061 (from 2 to 5 sections) + 471202
